BIOS SETUP
Integrated Peripherals
Phoenix - AwardBIOS CMOS Setup Utility
Integrated Peripherals
On-Chip Primary IDE Device Press Enter ITEM HELP
Onboard Device Press Enter Menu Level
SuperIO Device Press Enter
Phoenix - AwardBIOS CMOS Setup Utility
OnChip IDE Device
IDE Block Mode Enabled ITEM HELP
On-Chip Primary PCI IDE Enabled Menu Level
IDE Primary Master PIO Auto
IDE Primary Slave PIO Auto
IDE Primary Master UDMA Auto
IDE Primary Slave UDMA Auto
On-Chip Secondary PCI IDE Enabled
IDE Secondary Master PIO Auto
IDE Secondary Slave PIO Auto
IDE Secondary Master UDMA Auto
IDE Secondary Slave UDMA Auto
*** On-Chip Serial ATA Setting ***
SATA Mode
On-Chip Serial AT A IDE
Auto
Serial ATA Port0 Mode SATA0 master
Serial ATA Port1 Mode SATA1 master
Phoenix - AwardBIOS CMOS Setup Utility
Onboard Device
USB Controller Enabled ITEM HELP
USB 2.0 Controller Enabled Menu Level
USB Keyboard Support Disabled
USB Mouse Support Disabled
AC97 Audio Auto
CSA L AN (Giga-LAN)
Init Display First Enabled
PCI Slot
Phoenix - AwardBIOS CMOS Setup Utility
SuperIO Device
Onboard FDC Controller Enabled ITEM HELP
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
UART Mode Select Normal
RxD , TxD Active Hi, Lo
IR Transmission Delay Enabled
UR2 Duplex Mode Half
Use IR Pins IR-Rx2T x2
Onboard Parallel Port 378/IRQ7
Parallel Port Mode SPP EPP
Mode Select EPP1.7
Menu Level >
ECP Mode Use DMA
Onboard Serial Port 3
Serial Port 3 Use IRQ
Onboard Serial Port 4
Serial Port 4 Use IRQ 3
3E8
IRQ11
Disabled
IRQ10
PWRON After PWR-Fail Off
40 2801550 User’s Manual
