Table of Contents
Introduction
.......................................................1
Product Description............................................................. 1
Checklist.............................................................................. 2
Specifications ...................................................................... 3
Board Dimensions ............................................................... 4
Installations
.......................................................5
Installing the CPU ............................................................... 6
ATX Power Installation ...................................................... 6
Installing the Memory ......................................................... 7
Setting the Jumpers ............................................................. 8
Connectors on 2801550 ...................................................... 12
Watchdog Timer Configuration ........................................ 24
BIOS Setup
.......................................................27
Drivers Installation
......................................51
Intel 865G Chipset Software Intallation Utility ................ 52
Intel 865G Chipset Graphics Driver.................................. 55
Realtek AC97 Codec Audio Driver Installation................ 57
Intel PRO LAN Drivers Installation.................................. 58
Appendix
...........................................................59
A. I/O Port Address Map................................................... 59
B. Interrupt Request Lines (IRQ) ...................................... 60
2801550 User’s Manual iii
