Part Number Description Qty Reference Designator
INPUT/RABOS PCB
Capacitors
129-a102j633 metalized Capacitor 0.001uF 63V ± 5% MSC 1 C148
129-a103j633 metalized Capacitor 10NF 63V 1 C183
129-a104j633 metalized Capacitor 0.1U 63V ± 5% MSC 6 C116,137,138,139,143,118
129-a223j633 metalized Capacitor 0.022U 63V ± 5% MSC 1 C150
129-a224j633 metalized Capacitor 0.22uF 63V ± 5% MSC 2 C121,C122
129-a473j633 metalized Capacitor 0.047U 63V ± 5% MSC 3 C117,C119,C149
130-2b102k503 disc Capacitor 1000P 50V ± 10% 2 C181,C182
130-2b221k503 disc Capacitor 220P 50V ± 10% 3 C107,C108,C128
130-3f104z503 disc Capacitor 0.1U 50V +80/-20% 13
C112,114,124,125,130,133,135,144,145,146,
147,153,154
130-3f473m503 disc Capacitor 0.047U 50V ± 20% 1 C180
130-sl101k503 disc Capacitor 100P 50V SL ± 10% 2 C110,C120
130-s1470k503 disc Capacitor 47P 50V ± 10% 1 C127
135-3105m50 electrolytic Cap 1U 50V ± 20% 1 C126
135-3106m50 electrolytic Cap 10uF 50V ± 20% 4 C109,C111,C123,C129
135-3107m16 electrolytic Cap 100uF 16V ± 20% 5 C113,115,132,134,136
135-3107m25 electrolytic Cap 100U 25V ± 20% 1 C152
135-3226m50 electrolytic Cap 22U 50V ± 20% 1 C151
139-3227m16 low leakage electrolytic Cap 220uF 16V ± 20% 1 C131
129-a683j633 metalized Capacitor 0.068uF 63V ± 5% MSC 1 C142
Semiconductors
192-027c1815gr Transistor 2SC1815GR NPN 3 Q101,Q102,Q103
197-031n4148 diode 100mA 75V SIGNAL IN4148 ROHM 7 D105,106,108,109,110,112,113
199-15000825 zener diode 8.2V 1/2W 52mm 1 D130
190-06m4558d IC.0PA 4558D DUAL OP-AMP 2 U101,U103
190-16t1072n I.C. TL072N DUAL OP-AMP 1 U105
190-16t1074cn I.C TL074CN ST QUAD OP-AMP 3 U102,U104,U106
192-153mpf102 I.C FAIRCHILD MPF102 FET 1 Q107
Miscellaneous
180-t000ts81 TACT switch L101 T2 LO-PASS,PHASE,RABOS 3 SW102,SW103,SW104
174-0rcb202vag RCA JACK RCA-209 1 JK102
175-1c02p01 coupling 2PIN PITCH=2.5mm 2 P106,P101
CLASS D AMP PCB
Resistors
118-12061001j SMD Resistor 1.00K 1206 5% 1 R2
118-12061002j SMD Resistor 10.0K 1206 5% 6 R25,29,30,30B,7,9
118-120610r0j SMD Resistor 10.0Ω 1206 5% 4 R20,R20B,R22,R23
118-12062002j SMD Resistor 20.0K 1206 5% 1 R26
118-12062201j SMD Resistor 2.20K 1206 5% 19
R6,13,16,31,33,34,34,35,37,38,39,40,41,42,4
3,44,45,46,32
118-12062204j SMD Resistor 2.20M 1206 5% 1 R4
118-12062701j SMD Resistor 2.70K 1206 5% 1 R10
118-12063000j SMD Resistor 300.0Ω 1206 5% 1 R24
118-12063301j SMD Resistor 3.30K 1206 5% 5 R1,14,15,27,28
118-12063902j SMD Resistor 39.0K 1206 5% 1 R3
118-12064700j SMD Resistor 470Ω 1206 5% 3 R8,R11,R21
118-12064701j SMD Resistor 4.70K 1206 5% 2 R5,R12
112-10180j00 fusible Resistor FMF 1W 18Ω5% 1
Capacitors
141-c0101k50 SMD Capacitor 100pF 50V 10% 1206 NP0 1 C4
141-c0220k50 SMD Capacitor 22pF 50V 10% 1206 SMT NP0 1 C5
141-c0561k50 SMD Capacitor 560pF 50V 10% 1206 NP0 1 C6
141-c5104m50 SMD Capacitor 1206 Y5V 0.1uF 50V±20% 8 C2,3,7,8,9,10,11,15
15
