TSS-SUB4000 120V Electrical Parts List
Part Number
Description
Qty
Reference Designator
MAIN PCB
Resistors
110-12621j15
Resistor 620Ω1/2W ± 5% 15mm
1
R238
110-16102j26
Resistor 1K 1/6W ± 5% CF 26mm
3
R210,R239,R264
110-16103j26
Resistor 10K 1/6W ± 5% CF 26mm
9
R227,229,230,231,232,233,260,261,263
110-16153j26
Resistor 15K 1/6W ± 5% CF 26mm
2
R247,R249
110-16182j26
Resistor 1.8K 1/6W ± 5% CF 26mm
1
R248
110-16222j26
Resistor 2.2K 1/6W ± 5% CF 26mm
2
R242,R245
110-16223j26
Resistor 22K 1/6W ± 5% CF 26mm
3
R218,R220,R223
110-16274j26
Resistor 270K 1/6W ± 5% CF 26mm
1
R240
110-16333j26
Resistor 33K 1/6W ± 5% CF 26mm
1
R211
110-16391j26
Resistor 390Ω1/6W CF 26mm
2
R243,R246
110-16432j26
Resistor 4.3K 1/6W ± 5% CF 26mm
1
R254
110-16472j26
Resistor 4.7K 1/6W ± 5% CF 26mm
4
R217,219,222,213
110-16473j26
Resistor 47K 1/6W ± 5% CF 26mm
1
R221
110-16683j26
Resistor 68K 1/6W ± 5% CF 26mm
1
R212
122-14101j26
fusible Resistor 1/4W 100ohm 5%
2
R241,R244
116-141r00j26x
metal film Resistor 1.00Ω1/4W ± 5% MO 26mm
2
R256,R255
116-161001f26
metal film Resistor 1K 1/6W ± 1% MF 26mm
2
R252,R253
116-161002f26
metal film Resistor 10K 1/6W ± 1% MF 26mm
2
R234,R235
116-161022f26
metal film Resistor 10.2K 1/6W MF 26mm
1
R251
116-161301f26
metal film Resistor 1.30K 1/6W MF 26mm
3
R226,R228,R236
116-161822f26
metal film Resistor 18.2K 1/6W ± 1% MF 26mm
1
R214
116-162001f26
metal film Resistor 2.00K 1/6W ± 1% MF 26mm
1
R215
116-162492f26
metal film Resistor 24.9K 1/6W ± 1% MF 26mm
2
R257,R258
116-164320f26
metal film Resistor 432Ω 1/6W ± 1% MF 26mm
1
R265
116-166813f26
metal film Resistor 681K 1/6W ± 1% MF 26mm
1
R262
110-20152j20
Resistor 1.5K 2W ± 5% CF 20mm KINK
1
R208
113-500r1j10
cement Resistor 0.1Ω5W ± 5%
2
R224,R225
116-142003f26
metal film Resistor 200K 1/4W ± 1% MF 26mm
1
R209
Capacitors
130-2b102k503
disc Capacitor 1000P 50V ± 10%
1
C165
130-3f104z503
disc Capacitor 0.1U 50V +80/-20%
2
C163,C164
130-ch101j503
disc Capacitor 100P 50V ±5%
2
C159,C160
135-3107m16
electrolytic Cap 100uF 16V ±20%
2
C166,C167
135-3226m50
electrolytic Cap 22U 50V ±20%
2
C161,C162
135-3227m10
electrolytic Cap 220U 10V ±20%
2
C156,C157
139-3227m16
low leakage ec 220uF 16V ± 20%
1
C155
140-rx103ka03
multylayer Cap 10nF 100V X7R 10%
1
C174
140-rx473kb03
multylayer Cap 47nF 200V X7R ± 10%
2
C172,C173
135-4228m35
electrolytic Cap 2200uF 35V ± 20%
2
C170,C171
135-4688m80
electrolytic Cap 6800U 80V ± 20%
2
C168,C169
Semiconductors
190-161431c1p1
IC TL431CLP Shunt Regulator
1
D115
192-027c1815gr
Transistor 2SC1815GR NPN
4
Q110,112,114,117
192-028a1015gr
Transistor 2SA1015GR PNP
3
Q111,113,115
192-1572n5551
Transistor FSC 2N5551 NPN
1
Q109
192-1582n5401
Transistor FSC 2N5401 AI-PNP 350V 500mA TO-92
1
Q108
197-031n4148
diode 100mA 75V SIGNAL IN4148 ROHM
7
D118,119,120,121,125,126,117
199-15000565
ZENER diode 5.6V 1/2W 52mm
1
D116
199-15001505
ZENER diode 15V 1/2W 52mm
1
D122
199-15002005
ZENER diode 20V 1/2W 52mm
1
D129
192-991d669a
Transistor HI-SINCERITY HSD669A NPN
1
Q116
192-992b649t
Transistor HSB649T PNP
1
Q118
190-161m324n
I.C.LM324N QUAD OP-AMP
1
U107
197-00db103g
diode 1A 200V DF02M DB103G BRIDGE
1
D124
197-00kbu1003
diode 10A 200V KBU1003 BRIDGE
1
D123
197-101n4002
diode 1N4002
1
D114
