Part Number
Description
Qty
Reference Designator
MAIN PCB
Miscellaneous
109-1tsc103j0
thermister TSC05103J
1
R237
162-10229004
wire assy 220mm AWG28
1
P107
171-udhss124d
relay 5A 24V UDH-SS124D
1
K101
175-1c02p01
coupling 2PIN PITCH=2.5mm
1
P108
175-1c06v01
coupling 6PIN PITCH=2.5mm
1
P105
175-1d02v01
coupling 2PIN PITCH=3.96mm
1
P112
INPUT/RABOS PCB
Resistors
110-14152j26
Resistor 1.5K 1/4W ± 5% CF 26mm
1
R150
110-16101j26
Resistor 100Ω1/6W ± 5% CF 26mm
4
R112,R113,R151,R152
110-16102j26
Resistor 1K 1/6W ± 5% CF 26mm
2
R140,R196
110-16103j26
Resistor 1K 1/6W ± 5% CF 26mm
9
R118,126,129,133,136,146,149,199,156
110-16105j26
Resistor 1M 1/6W ± 5% CF 26mm
2
R145,R181
110-16106j26
Resistor 10M 1/6W ± 5% CF 26mm
1
R186
110-16151j26
Resistor 150Ω1/6W ± 5% CF 26mm
1
R139
110-16154j26
Resistor 150K 1/6W ± 5% CF 26mm
1
R138
110-16183j26
Resistor 18K 1/6W ± 5% CF 26mm
1
R147
110-16203j26
Resistor 20K 1/6W ± 5% CF 26mm
1
R200
110-16221j26
Resistor 220Ω1/6W ± 5% CF 26mm
2
R119,R120
110-16223j26
Resistor 22K 1/6W ± 5% CF 26mm
2
R141,R148
110-16472j26
Resistor 4.7K 1/6W ± 5% CF 26mm
1
R144
110-16473j26
Resistor 47K 1/6W ± 5% CF 26mm
1
R137
110-16474j26
Resistor 470K 1/6W ± 5% CF 26mm
1
R143
110-164r7j26
Resistor 4.7Ω1/6W ± 5% CF 26mm
1
R153
116-161000f26
metal film Resistor 100Ω1/6W ± 1% MF 26mm
1
R154
116-161001f26
metal film Resistor 1K 1/6W ± 1% MF 26mm
12
R130,131,132,159,160,166,171,173,178,192,
114,115
116-161103f26
metal film Resistor 100K 1/6W ± 1% MF 26mm
1
R174
116-161502f26
metal film Resistor 15.0K 1/6W ± 1% MF 26mm
2
R162,R168
116-161504f26
metal film Resistor 1.5M 1/6W ± 1% MF 26mm
1
R142
116-161622f26
metal film Resistor 16.2K 1/6W ± 1% MF 26mm
1
R188
116-161742f26
metal film Resistor 17.4K 1/6W ± 1% MF 26mm
4
R124,R125,R127,R128
116-162001f26
metal film Resistor 2.00K 1/6W ± 1% MF 26mm
1
R202
116-162052f26
metal film Resistor 20.5K 1/6W ± 1% MF 26mm
2
R197,R198
116-162211f26
metal film Resistor 2.21K 1/6W ± 1% MF 26mm
1
R172
116-162212f26
metal film Resistor 22.1K 1/6W ± 1% MF 26mm
3
R193,R204,R206
116-162671f26
metal film Resistor 2.67K 1/6W ± 1% MF 26mm
1
R155
116-163323f26
metal film Resistor 332K 1/6W ± 1% MF 26mm
1
R195
116-163400f26
metal film Resistor 340Ω1/6W ± 1% MF 26mm
2
R164,R169
116-163571f26
metal film Resistor 3.57K 1/6W ± 1% MF 26mm
1
R157
116-163923f26
metal film Resistor 392K 1/6W ± 1% MF 26mm
1
R201
116-164751f26
metal film Resistor 4.75K 1/6W ± 1% MF 26mm
2
R109,R110
116-164752f26
metal film Resistor 47.5K 1/6W ± 1% MF 26mm
2
R121,R122
116-164992f26
metal film Resistor 49.9K 1/6W ± 1% MF 26mm
1
R135
116-165231f26
metal film Resistor 5.23K 1/6W ± 10% MF
2
R205,R207
116-165232f26
metal film Resistor 52.3K 1/6W MF 26mm
1
R190
116-165400f26
metal film Resistor 540Ω1/6W MF 26mm
1
R175
116-166041f26
metal film Resistor 6.04K 1/6W ± 1% MF 26mm
2
R165,R170
116-166800f26
metal film Resistor 680Ω1/6W ± 1% MF 26mm
1
R176
116-168250f26
metal film Resistor 825Ω1/6W ± 1% MF 26mm
2
R161,R167
116-168661f26
metal film Resistor 8.66K 1/6W ± 1% MF 26mm
1
R134
116-169311f26
metal film Resistor 9.31K 1/6W ± 1% MF 26mm
2
R189,R179
115-h103a101
variable Resistor A10K LEVEL
1
R259
115-h103a203
variable Resistor RV16A01-20-15K-A10K-3E RABOS
LEVEL, RABOS WIDTH
2
R158,R177
115-h103c201
variable Resistor RV16A01-20-15K-C10K-3E RABOS FREQ.
1
R163
