Shrouds, Frames and Anti-Tippers

Item

Number

Part Number

Description

Note

Quantity Per

Package Assembly

1057530-NLA

NLA - Screw, Phillips Pan Head (#6-32 x 1")

1

4

1

0204705-NLA

NLA - Washer, Flat (#6)

1

4

2

0143205-NLA

NLA - Locknut, Low Profile (#6-32)

1

4

3

0226400-NLA

NLA - Clip, Rear Shroud Fastener

1

2

4

1056270-NLA

NLA - Plug Button, Black (1-1/4")

1

1

5

1055726-NLA

NLA - Tray, Battery

1

2

6

0230800-NLA

NLA - Rivet (1/8 X 1/2" Long)

1

16

7

H

16348X000

Rivet (3/16 x 7/16")

1

10

7

I

1055721-NLA

NLA - Mat, Floor - Right

1

1

8

H

1055720-NLA

NLA - Mat, Floor - Left

1

1

8

H

1080966

Mat, Floor - Right

1

1

8

I

1080967

Mat, Floor - Left

1

1

8

I

1077138-NLA

NLA - Shroud, Front with Decals

1

1

9

B

1070128-NLA

NLA - Decal, Cat Basic

1

4

10

1081503-NLA

NLA - Kit, Front Shroud Hardware

1

1

11

D,H

1080895-NLA

NLA - Kit, Front Shroud Hardware

1

1

11

E,I

1056269-NLA

NLA - Knob, Tee

1

2

12

0226500-NLA

NLA - Knob, Tee

1

2

12

1055675-NLA

NLA - Decal, Brake Release

1

1

13

1056258-NLA

NLA - Decal, Reflector

1

1

14

1077137-NLA

NLA - Shroud, Rear with Decals

1

1

15

1077793-NLA

NLA - Screw, Socket Head (1/4-20 x 3/4")

1

2

16

1081504-NLA

NLA - Kit, Rear Shroud Hardware

1

1

17

F,H

1080894-NLA

NLA - Kit, Rear Shroud Hardware

1

1

17

G,I

1070575-NLA

NLA - Screw, SEMS w/ Washer (#10-32 x 7/8")

1

2

18

40315X000

Rivet, Nut (#10-32)

1

2

19

1039773

Screw, Phillips Pan Head (#6-32 x 1-1/8")

1

4

20

1043599

Washer, Flat (5/32 x 3/8 x 1/32")

1

4

21

40157X003

Washer, Plain (5/16 x 5/8 x 1/8")

1

4

22

P0870X050

Nut, Keps (#6-32)

1

4

23

1060994-NLA

NLA - Pad, Battery Tray

1

2

24

1021742

Screw, Phillips Pan Head (#4-40 x 1/2")

1

2

25

P0870X000

Nut, Hex Keps (#4-40)

1

2

26

1086234-NLA

NLA - Anti-Tipper Assembly

1

2

27

C,J

1055665-NLA

NLA - Lock, Spring

1

2

28

1072717-NLA

NLA - Frame, Chassis, Black

1

1

29

H

1080882-NLA

NLA - Frame, Long, Black

1

1

29

A,I

16720X004

Screw, Hex Head (1/4-20 x 1-1/2")

1

2

30

1055684-NLA

NLA - Wheel, Anti-Tip 2"

1

2

31

1025195

Locknut (1/4-20)

1

2

32

1055662

Plug Button, Square, Black (1-1/8")

1

2

33

6
