Invacare Discontinued 1/00 - Manual (Page 22)

Seat Plate Assembly
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1072154 Collar - Lower 1 1 1
1072153-NLA NLA - Collar - Upper 1 1 2
16720X004 Screw, Hex Head (1/4-20 x 1-1/2") 1 2 3
0050506 Lockwasher, High Collar, Split (1/4") 1 4 4
1009000-NLA NLA - Washer (3/4 x 1/4 x 1/16") 1 4 5
1072155-NLA NLA - Kit, Seat Plate Assembly without Hardware 1 1 6 A
1071285-NLA NLA - Kit, Seat Plate Assembly - Right Release 1 1 6 B
1071997-NLA NLA - Kit, Seat Plate Assembly - Left Release 1 1 6 C
0230800-NLA NLA - Rivet (1/8 X 1/2" Long) 1 1 7
0051705-NLA NLA - Screw, Hex Head (1/4-20 x 1") 1 2 8
1055677-NLA NLA - Washer, Seat Base (1-1/2 x 2 x 3/32") 1 1 9
1077181 Screw, Socket Head (#6-32 x 3/4") 1 4 10
1072959-NLA NLA - Plate, Sprocket 1 1 11
1055687-NLA NLA - Bearing, Nyliner 1 1 12
1055768-NLA NLA - Locknut (#6-32) 1 4 13
0143205-NLA NLA - Locknut, Low Profile (#6-32) 1 4 13
1055693-NLA NLA - Cap, Handle 1 1 14
1073714-NLA NLA - Handle, Swivel Bar, Black 1 1 15
1026907 Washer (1/4 x 1/2 x 1/16") 1 2 16
1025195 Locknut (1/4-20) 1 1 17
1070179-NLA NLA - Plate, Slate 1 1 18
1039883 Screw, Hex Head w/ Patch (1/4-20 x 1") 1 1 19
1075062-NLA NLA - Spring, Compression 1 1 20
1038785 Pin, Roll (1/8 x 3/8") 1 2 21
1058766-NLA NLA - Post, Seat 1 1 22
1081172 Kit, Seat Post Attaching Hardware 1 1 23
A - Before 1/9/98 without handle
B - After 1/8/98
C - After 10/18/98 NOTE:
21
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 95-09
