Motor and Trans-Axle
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1058529-NLA NLA - Mount, Vibration 1 2 1
1058043-NLA NLA - Key, Wheel 1 2 2
1055767-NLA NLA - Screw, Hex Head (#8-32 x 3/8") 1 4 3
1055717-NLA NLA - Brake, ASI 1 1 4 C
1062475 Brake, Stature 1 1 4 D
1055690-NLA NLA - Cap, Brake Lever 1 1 5
1058522-NLA NLA - Motor and Brake Assembly, ASI 1 1 6 C
1070596-NLA NLA - Motor and Brake Assembly, Stature 1 1 6 E
1086251-NLA NLA - Motor and Brake Assembly, Stature 1 1 6 F
1058527-NLA NLA - Coupling, ASI 1 1 7 C
1062477-NLA NLA - Coupling, Stature 1 1 7 D
1058528-NLA NLA - Key, Motor Gearbox 1 1 8
1058524-NLA NLA - Kit, Brush, ASI 2 1 9 C
1062476-NLA NLA - Kit, Brush, Stature 2 1 9 D
1003766 Washer, Plain (1/2 x 1 x 1/8") 1 2 10
1001979 Locknut (1/2-20) 1 2 11
1058042-NLA NLA - Ring, Grip 1 2 12 B
1058041-NLA NLA - Trans-Axle Assembly, ASI with Brake 1 1 13 A,C
1062535-NLA NLA - Trans-Axle Assembly, Stature with Brake 1 1 13 E
1085944-NLA NLA - Trans-Axle Assembly, Stature with Brake 1 1 13 F
A - Trans-Axle 1058041 is NLA, order Trans-Axle 1062535 as a direct replacement.
B - Includes items 1-12
C - Before 7/27/98
D - After 7/26/98
E - 7/27/98 thru 1/27/99
F - After 1/27/99 NOTE:
17
