Tiller Assembly and Controller
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1055728-NLA NLA - Face Plate Assembly without Throttle Lever -
Right 1 1 1 D
1081272-NLA NLA - Face Plate Assembly without Throttle Lever
(D.S. 70) - Right 1 1 1 E
1081414 Face Plate Assembly without Throttle Lever (D.S.
70) - Left 1 1 1 E
0307200-NLA NLA - Clamp, Throttle - Lower 1 1 2
0307322-NLA NLA - Clamp, Throttle - Upper 1 1 2 D
1055672-NLA NLA - Clamp, Throttle - Upper (D.S. 70) 1 1 2 E
1016301 Washer, Nylon (5/16 x 7/8 x 1/8") 1 1 3
1056260-NLA NLA - Lever, Throttle - Standard 1 1 4
1055680 Decal, Forward 1 1 5
1055667 Decal, Reverse 1 1 6
1014386 Screw, Phillips Pan Head (#8-32 x 5/8") 1 2 7
1055740-NLA NLA - Screw, Socket Flat Head (#8-32 x 1/2") 1 2 8
1055661-NLA NLA - Grip, Hand 1 2 9
1072707-NLA NLA - Harness Assembly - Tiller 1 1 10
98007X005 Tie Wrap (11-1/2" L) 1 2 11
1055679-NLA NLA - Boot 1 1 12
1081536-NLA NLA - Tiller Assembly - Right 1 1 13 C,D
1081406-NLA NLA - Tiller Assembly (D.S. 70) - Right 1 1 13 C,E
1081385-NLA NLA - Tiller Assembly (D.S. 70) - Left 1 1 13 C,E
1055727-NLA NLA - Controller Assembly 1 1 14 D
1071456-NLA NLA - Controller Assembly (D.S. 70) 1 1 14 E,F
1085941-NLA NLA - Controller Assembly (D.S. 70) 1 1 14 G
0194500-NLA NLA - Keys 2 1 B
1056928 Decal, Grey 1 1 A,B
A - Decal no longer used after 9/14/98
B - Not Shown.
C - Includes items 1-12
D - Before 5/15/98
E - After 5/14/98
F - 5/15/98 thru 1/27/99
G - After 1/27/99 NOTE:
9
