PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Lat Bar 1
2 C-clip 6
3 Chain 3
4 2” x 2 ¾” End Cap 3
5 M10 Aircraft Nut 14
6 Bushing 6
7 M10 x 2 ½” Allen Bolt 4
8 Upper Frame 1
9 Pulley 8
10 119 “ Upper Cable 1
11 M12 x 3 1/8” Carriage Bolt 4
12
∅
1” Washer 15
13 M12 Aircraft Nut 8
14 Top socket Assembly 1
15 Guide Rod Ring 2
16 M8 x ½” Allen Bolt 4
17 M10 x 2” Allen Bolt 5
18 Guide Rod 2
19 Rear Vertical Beam 1
20 Plastic Bushing 4
21 Pulley Bracket 2
22 Front Vertical Beam 1
23 104” Lower Cable 1
24 Weight Holder 1
25
∅
1” End Cap 1
26 Rubber Washer 4
27 Rubber Bumper 2
28 Guide Rod Sleeve 2
29 M12 x 1” Allen Bolt 7
30 Olympic Sleeve 2
31 Spring Clip Sleeve 4
32 Spring Clip 2
33 Rear Stabilizer 1
34 Olympic Sleeve End Cap 2
35 Main Stabilizer 1
36 M10 x 1” Round Allen Bolt 5
37 Horse Shoe End Cap 5
38 M12 x 4” Carriage Bolt 4
39 2” Square End Cap 2
40 Foot Plate Support 1
41 Foot Plate 1
42 M10 x 1” Allen Bolt 4
43
∅
¾” Washer 18
44 M10 x 3” Allen Bolt 1
45 Base Frame 1
46 Lock Knob 3
47 Seat Adjustment Frame 1
48 Plastic Sleeve 3
49 M8 x 1 3/8” Allen Bolt 4
50
∅
5/8” Washer 4
51 Seat Pad 1
52 Seat Post 1
53 Seat Frame 1
54 Arm Curl Stand 1
55 Arm Curl Pad 1
56 Curl Bar 1
57 Double D-bar Handle 1
