PC 300 GL and 300 PL
Input/output address map
The following lists resource assignments for the I/O address map. Any addresses
that are not shown are reserved.
Table 33. I/O address map
Address (hex)
Size
Description
0000–000F
16 bytes
DMA 1
0010–001F
16 bytes
General I/O locations - available to PCI bus
0020–0021
2 bytes
Interrupt controller 1
0023–003F
30 bytes
General I/O locations - available to PCI bus
0040–0043
4 bytes
Counter/timer 1
0044–00FF
28 bytes
General I/O locations - available to PCI bus
0060
1 byte
Keyboard controller byte - reset IRQ
0061
1 byte
System port B
0064
1 byte
Keyboard controller, CMB/STAT byte
0070, bit 7
1 bit
Enable NMI
0070, bits 6:0
1 bit
Real-time clock, address
0071
1 byte
Real-time clock, data
0072–007F
14 bytes
General I/O locations - available to PCI bus
0080
1 byte
POST checkpoint register during POST only
008F
1 byte
Refresh page register
0080–008F
16 bytes
ICH1, DMA page registers
0090–0091
15 bytes
General I/O locations - available to PCI bus
0092
1 byte
PS/2 keyboard controller registers
0093–009F
15 bytes
General I/O locations
00A0–00A1
2 bytes
Interrupt controller 2
00A2–00BF
30 bytes
APM control
00C0–00DF
31 bytes
DMA 2
00E0–00EF
16 bytes
General I/O locations - available to PCI bus
00F0
1 byte
Coprocessor error register
00F1–016F
127 bytes
General I/O locations - available to PCI bus
0170–0177
8 bytes
Secondary IDE channel
01F0–01F7
8 bytes
Primary IDE channel
0200–0207
8 bytes
Available
0220–0227
8 bytes
Serial port 3 or 4
0228–0277
80 bytes
General I/O locations - available to PCI bus
0278–027F
8 bytes
LPT3
