ICH8—NVM Information Guide
1.4.15 Shared Initialization Control (Word 13h)
This word controls general initialization values.
Table 11. Shared Initialization Control (Word 13h)
Bit Name Default Description
15:14 SIGN 10b
Valid Indication
This is a 2-bit field indicating whether a valid NVM is present to the
MAC. If this field does not equal 10b, the MAC does not read the
NVM data and uses default values for device configuration.
00b = Invalid NVM.
01b = Invalid NVM.
10b = Valid NVM present.
11b = Invalid NVM.
13:11 Reserved 010b These bits are reserved and should be set to 010b.
10 Reserved 1b Reserved. Always set to 1b.
9 PHY PD Ena 1b
For ICH8 designs that support an ACBS implementation using LAN
Power Control (LAN_PHYPC), this bit enables or disables PHY power
down.
0b = PHY power down feature is disabled.
1b = PHY power down feature is enabled to power down at DMoff/
D3 without Wake on LAN.
This bit is loaded to the PHY Power Down Enable bit in the
CTRL_EXT register.
8 Reserved 0b This bit is reserved and should be set to 0b.
7:6 PHYT 00b
This field indicates the PHY device type.
00b = 82566 PHY - GLCI mode
01b = Reserved
10b = 82562V PHY - PCIe mode, LCI mode
11b = Reserved
This field is reflected in the PHYTYPE field in the Status register.
5 Reserved 0b Reserved. Must be set to 0b.
4 FRCSPD 0b
Force Speed Enable
0b = Normal operation.
1b = Use ICH8 speed.
3 FD 0b
Force Duplex
0b = Normal operation.
1b = Use ICH8 speed.
2 CLK_CNT_1_16 1b
This bit is loaded to the CTRL_EXT.EnaKumCK16 bit and enables
the reduction of the internal JCLK to one-sixteenth of the external
NJCLK at the GLCI interface in Gigabit Ethernet mode.
0b = Reduction is disabled.
1b = Reduction is enabled.
1 CLK_CNT_1_4 0b
This bit enables the automatic reduction of DMA frequency. It is
mapped to STATUS[31].
0b = Automatic reduction disabled.
1b = Automatic reduction enabled.
0
Dynamic Clock
Gating
1b
Dynamic Clock Gating
0b = Disable.
1b = Enable.
