Leadership enterprise server with significantly lower cost of ownership in a highly available and
expandable, rack-dense, 2U dual-socket server
Please see the Legal Information section for important notices and information.
18
# of 33MHz legacy PCI slots
None
# of video ports
2 (one front, one rear)
Video controller
Matrox G200eV (in IMM) standard
(NVIDIA FX580, 1800, or 3800 available for CTO and special-bid models)
Video memory
16MB DDR2 SDRAM
Maximum video resolutions
1280x1024 at 60Hz (32 bits)
1600x1200 at 85Hz (16 bits)
Gigabit Ethernet controller
Broadcom BCM5709S
TOE / iSCSI / RDMA acceleration
TOE only
# of Gigabit Ethernet ports
2 standard plus 2 optional
# Emulex 10GbE Integrated Virtual Fabric
Adapter for IBM
2 ports available via CTO
# of RS485 ports
None
# of serial ports
1 (rear)
# of parallel ports
None (USB-attached)
# of mouse ports
None (USB-attached)
# of keyboard ports
None (USB-attached)
# of USB 2.0 ports
5 (2 front, 2 rear, 1 internal for an optional tape drive, IBM RDX disk storage device,
or USB flash memory key containing an embedded hypervisor)
Integrated systems management controller
Yes (IMM)
Optional systems management adapter
Virtual Media Key (optional)
Light path diagnostics support
Yes,
with external pop-out/drop-down panel
Predictive Failure Analysis (PFA) support
Processors, memory, voltage regulator modules (VRMs), power supplies and fans
Power supply size
675W universal, autoswitching, hot-swap; 92% efficiency
# of power supplies standard / maximum
2 / 2 (F2x)
1 / 2 (all other models)
Hot-swap/redundant power supported
Yes (with two power supplies installed)
# of fans modules standard / maximum
3 / 3 (2 fans per module)
Hot-swap/redundant fans supported
Yes (standard)
Rack mount method
Slides and Cable Management Arm (provided standard)
Maximum altitude
7,000 ft;
2,133 m
Operating temperature range
50 – 95º F; 10 – 35º C (up to 3,000 ft /
914.4 m)
50 – 90º F; 10 – 32º C (3,000 ft to 7,000
ft / 914.4m to 2,133m)
Dimensions (HWD) / weight
3.36” (85.4mm) H
17.5” (443.6mm) W
27.5” (798mm) D
46.5 (minimum) – 55.1 lb (maximum)
21.1 – 24.9 kg
Operating systems supported
Microsoft Windows Server 2008 / 2008 R2, 32/64-bit; Microsoft Windows Server 2003
/ 2003 R2 (Standard/Enterprise/Web/Datacenter/Datacenter with UV), 32/64-bit;
RHEL 4 (AS/ES/WS) 32-bit without Xen; RHEL 5 32/64-bit, with and without Xen;
SLES 10/11 32/64-bit with and without Xen; VMware ESX Server 4.0, ESXi 4.0; Sun
Solaris 10
8
Length of limited warranty
3 years (parts and labor)
9
8
Support planned for 2Q/2010.
9
For terms and conditions or copies of the IBM Statement of Limited Warranty, call 800-772-2227 in the U.S. In Canada call 800-
426-2255. IBM makes no representation or warranty regarding third-party products or services including those designated as
