IBM System x3650 M3 Images
Front View
Inside View
Rear View
Hot-Swap Power
Supplies
USB
Hypervisor
Key
Hot-Swap
HDD Bays
Hot-Swap
Fan
Modules
18 DIMM Slots
Processor
Socket
ServeRAID
Controller
Gb Ethernet
Adapter Slots
Adapter Slots
Processor /
Heat Sink
Empty Hot-Swap
2.5” HDD Bays
Status
Lights
Pop-Out/Drop-Down Light
Path Diagnostics Panel
Optical Drive
Video Port
Power
Button
USB 2.0
Ports
Hot-Swap 2.5”
HDDs Empty HDD
Fillers
Light Path Diagnostics
Panel Eject Button
Light Path
Diagnostics Panel
Eject Button
Video
Port Serial Port
Adapter Slots Adapter Slots
Fast Ethernet
Port for IMM USB Ports Optional Gb
Ethernet Ports Hot-Swap
Power Supply
Standard Gb Ethernet Ports
Hexagonal
Ventilation
Holes
Empty Hot-Swap
Power Supply Bay
Hexagonal Ventilation
Holes
