IBM X3650 M3 - Manual (Page 17)

Leadership enterprise server with significantly lower cost of ownership in a highly available and
expandable, rack-dense, 2U dual-socket server
Please see the Legal Information section for important notices and information.
17
(* When available in 2Q/2010) 1333MHz RDIMM
2GB single-rank x4,
1.5V;
2GB single-rank x8 1.5V;
2GB dual-rank x8 1.5V;
2GB dual-rank x8 1.35V;
4GB dual-rank x4 1.5V;
4GB dual-rank x4 1.35V;
8GB dual-rank x4 1.5V;
*8GB dual-rank x4 1.35V
1333MHz UDIMM
2GB dual-rank x8 1.5V;
*4GB dual-rank x8 1.35V
1066MHz RDIMM
*8GB dual-rank x4 1.35V;
*16GB quad-rank x4 1.5V
Supports 1333MHz with 2 DIMMs per
channel L5640 and X56xx processors support 2DPC at 1333MHz;
X55xx processors support 2DPC at 1333MHz via the special bid process
Online hot-spare memory supported No
Memory mirroring supported / # of DIMM
sockets reserved for mirroring
Yes / 1 channel (3 slots per processor) active, 1 spare, 1 unused
# of HDD drive bays total / available 16 / 16 (2.5-inch) 8 / 8 (2.5-inch) with internal tape drive
# of 5.25" bays total / available 1 / 1
Maximum drive capacity (supports mixing
SAS/SATA/SSD)
2.5-inch
SAS/SATA
8.0TB (16 x
500GB) hot-swap
2.5-inch
SAS/SATA
4.0TB (8 x 500GB)
hot-swap, with
internal tape drive
2.5-inch SSD
800GB (16 x
50GB) hot-swap
2.5-inch SSD
400GB (8 x 50GB)
hot-swap or
simple-swap, with
internal tape drive
Drive capacities supported
2.5-inch HS SAS
500GB – 7.2K
73.4, 146.8, 300GB – 10K
73.4, 146.8GB —15K
2.5-inch HS SATA
160, 500GB – 7.2K
300GB – 10K
2.5-inch HS or SS SSD
50GB
# of HDDs standard None (all models open bay)
# of optical drives standard None (optional DVD-RW)
# of diskette drives standard None (optional)
Internal backup supported One tape drive (DDS Gen 5, DDS Gen 6) or RDX removable disk cartridge
Storage technology Hot-swap SAS/SATA; also hot-swap or simple-swap SSD
Integrated disk controller LSI 1068
# of disk drives supported per port 1
Integrated RAID controller standard
ServeRAID-
BR10il v2 (no
cache)—RAID-
0/1/1E, 3Gbps;
supports 4 drives
(A2x)
ServeRAID-M1015
(no cache)
optional battery—
RAID-0/1/10;
optional RAID-5
with SED, 6Gbps;
supports 16 drives
(B2x, C2x, D2x,
H2x, N2x)
ServeRAID-M5014
(256MB cache)
optional battery—
RAID-0/1/10/5/50;
optional RAID-
6/60 with SED,
6Gbps; supports
16 drives (F2x,
G2x)
ServeRAID-M5015
(512MB cache)
optional battery—
RAID-0/1/10/5/50;
optional RAID-
6/60 with SED,
6Gbps; supports
16 drives (J2x,
L2x, M2x)
Optional integrated RAID controllers
supported ServeRAID-M1015—
RAID-0/1/10 (A2x)
ServeRAID-M5014 (A2x,
B2x, C2x, D2x, H2x, N2x)
ServeRAID-M5015 (A2x,
B2x, C2x, D2x, F2x, G2x,
H2x, N2x)
External disk drives supported Yes, via the optional 3Gbps ServeRAID-MR10M controller (256MB cache standard—
SAS/SATA; adds RAID-0/1/10/5/50/6/60)
# of adapter slots total / available 4 / 4 (2 / 2 when using the CTO Emulex 10GbE Integrated Virtual Fabric Adapter)
# of PCIe x16 Gen 2 slots (16GBps) None standard (1 or 2 via optional risers in place of the x8 PCIe risers)
# of PCIe x8 Gen 2 slots (8GBps) 4 via 2 risers (2 full-height/full-length, 1 low-profile/full-length, 1 full-height/half-length)
# of PCI-X/133 slots (1GBps) None standard (1 or 2 via optional risers in place of the PCIe risers)
