Block diagram – Intel GA-8I945GZME-RH User Manual
Page 8
- 8 -
Block Diagram
LGA775
Processor
Host
Interface
Intel
945GZ
GMCH
DDRII 533MHz DIMM
4 Serial ATA
ATA33/66/100
IDE Channel
BIOS
PCICLK
(33MHz)
3 PCI
PCI Bus
Marvell
8001
RJ45
8 USB
Ports
Dual Channel Memory
Floppy
PS/2 KB/Mouse
LPT Port
VGA
Intel
ICH7
COM Ports
IT8718
PCI-ECLK
(100MHz)
PCI Express x4
Line-Out
MIC
CODEC
Line-In
SPDIF In
Side Speaker Out
Center/Subwoofer Speaker Out
Surround Speaker Out
SPDIF Out
