PANEL DESCRIPTION

3

t BATTERY INDICATOR

Indicates remaining battery power.

y VOX INDICATOR

“VOX” appears when the VOX function is used. (p. 10)

u SET MODE ITEM READOUT

Indicates the SET mode items while in the SET mode.
(p. 11)

i LOCK INDICATOR

Appears when the lock function is activated. (p. 10)

o CHANNEL NUMBER READOUT

Indicates the selected operating channel number.

In SET mode, indicates the selected condition.

!0 CALL CHANNEL INDICATOR

Appears when the call channel is selected. (p. 7)

Indication

Full

Middle Charging

required No battery

Battery level

blinks when the battery is over charged.

Using rechargeable battery pack

Indication

Full Middle A new battery

pack is required No battery

Battery level

Using BP-234 battery pack
