80960HA/HD/HT
Datasheet 97
entity Ha_Processor is
generic(PHYSICAL_PIN_MAP : string:= “PQ2”);
port (A : out bit_vector(2 to 31);
ADSBAR : out bit;
BEBAR : out bit_vector(0 to 3);
BLASTBAR : out bit;
BOFFBAR : in bit;
BREQ : out bit;
BSTALL : out bit;
BTERMBAR : in bit;
CT : out bit_vector(0 to 3);
CLKIN : in bit;
D : inout bit_vector(0 to 31);
DENBAR : out bit;
DP : inout bit_vector(0 to 3);
DTRBAR : out bit;
DCBAR : out bit;
FAILBAR : out bit;
HOLD : in bit;
HOLDA : out bit;
LOCKBAR : out bit;
NMIBAR : in bit;
ONCEBAR : in bit;
PCHKBAR : out bit;
READYBAR : in bit;
RESETBAR : in bit;
STEST : in bit;
SUPBAR : out bit;
TCK : in bit;
TDI : in bit;
TDO : out bit;
TMS : in bit;
TRST : in bit;
WAITBAR : out bit;
WRBAR : out bit;
XINTBAR : in bit_vector(0 to 7);
FIVEVREF : linkage bit;
VCCPLL : linkage bit;
Example 2. Boundary-Scan Description Language (BSDL) for PQ2
Package Example (Sheet 2 of 8)
