80960HA/HD/HT
90 Datasheet
SUPBAR : out bit;
TCK : in bit;
TDI : in bit;
TDO : out bit;
TMS : in bit;
TRST : in bit;
WAITBAR : out bit;
WRBAR : out bit;
XINTBAR : in bit_vector(0 to 7);
FIVEVREF : linkage bit;
VCCPLL : linkage bit;
VOLTDET : out bit;
VCC1 : linkage bit_vector(0 to 23);
VCC2 : linkage bit_vector(0 to 20);
VSS1 : linkage bit_vector(0 to 25);
VSS2 : linkage bit_vector(0 to 22);
NC : linkage bit_vector(0 to 4)
);
use STD_1149_1_1990.all;
use i960ha_a.all;
attribute PIN_MAP of Ha_Processor : entity is PHYSICAL_PIN_MAP;
constant PGA:PIN_MAP_STRING :=
“A : (D16, D17, E16, E17, F17, G16, G17, H17, J17,”&
“ K17, L17, L16, M17, N17, N16, P17, Q17, P16,”&
“ P15, Q16, R17, R16, Q15, S17, R15, S16, Q14, ”&
“ R14, Q13, S15),
“ADSBAR : R06,”&
“BEBAR : (R09, S07, S06, S05),”&
“BLASTBAR : S08,”&
“BOFFBAR : B01,”&
“BREQ : R13,”&
“BSTALL : R12,”&
“BTERMBAR : R04,”&
“CT : (A11, A12, A13, A14),”&
“CLKIN : C13,”&
Example 1. Boundary-Scan Description Language (BSDL) for PGA
Package Example (Sheet 3 of 8)
