Chapter 3 installation, 1 cpu installation – Intel IMB200VGE User Manual
Page 17
IMB200 LGA775 ATX MB User Manual
Installation 11
Chapter 3 Installation
Before installing the processor, Please pay more attention on Intel
website and obtained more information
http://www.intel.com.
3.1 CPU Installation
The LGA775 processor socket comes with a lever to protect the
processor. Please pay more attention as below. Follow the
pictures and place the processor into CPU socket.
.
