IMB200 LGA775 ATX MB User Manual
Award BIOS Utility 52
This option could allow you to set up Master IDE interface
from PIO mode0 to PIO Mode 4
z IDE Primary Slave PIO
This option could allow you to set up Slave IDE interface
from PIO mode 0 to PIO Mode 4
z IDE Primary Master UDMA
This option could allow you to enabled or disabled onboard
Ultra DMA mode on Primary Master
z IDE Primary Slave UDMA
This option could allow you to enabled or disabled onboard
Ultra DMA mode on Primary Slave
z On-Chip Serial ATA
This option could allow you to enabled or disabled onboard SATA
port function
Combined Mode : This option allows you to use both
IDE and SATA drive; allowing a maximum on 4 drives-1 IDE Master;
1 IDE Slave and 2 SATA. You must manually set the SATA and
PATA drives mode in the “ PATA IDE Mode “ and “ SATA Port
“ fields.
Enhanced Mode : This option allows you to use both IDE
And SATA drives; allowing a maximum of 6 drives – 1 IDE Master, 1
IDE Slave and 4 SATA.
SATA Only This option automatically sets the SATA
Drives to Primary Master Mode. Since the SATA drives are
In Master mode, you can not set the IDE drive to Master
Mode.
7.6.2 Onboard Device
Move the cursor to this field and press . The following
Screen will be appeared.
