Page 18
Intel Desktop Board D945GCLF2 Technical Product Specification
18
1.6.2
USB
The board supports up to eight USB 2.0 ports, supports UHCI and EHCI, and uses
UHCI- and EHCI-compatible drivers.
The ICH7 provides the USB controller for all ports. The port arrangement is as
follows:
• Four ports are implemented with dual stacked back panel connectors
• Four ports are routed to two separate front panel USB headers
NOTE
Computer systems that have an unshielded cable attached to a USB port may not
meet FCC Class B requirements, even if no device is attached to the cable. Use
shielded cable that meets the requirements for full-speed devices.
For information about
Refer to
The location of the USB connectors on the back panel
The location of the front panel USB headers
