4 AT Commands, S-Registers, and Result Codes
43
MultiModemZPX User Guide
Result Codes
In command mode your modem can send responses called result codes to your com-
puter. Result codes are used by communications programs and can also appear on
your monitor.
Terse
Verbose
Description
0
OK
Command executed
1
CONNECT
Modem connected to line
2
RING
Ring signal detected
3
NO CARRIER
Carrier signal lost or not detected
4
ERROR
Invalid command
5
CONNECT 1200 *
Connected at 1200 bps
6
NO DIALTONE
No dial tone detected
7
BUSY
Busy signal detected
8
NO ANSWER
No answer at remote end
10
CONNECT 2400 *
Connected at 2400 bps
11
CONNECT 4800 *
Connected at 4800 bps
12
CONNECT 9600 *
Connected at 9600 bps
13
CONNECT 14400 *
Connected at 14400 bps
14
CONNECT 19200 *
Connected at 19200 bps
24
CONNECT 7200 *
Connected at 7200 bps
25
CONNECT 12000 *
Connected at 12000 bps
26
CONNECT 16800 *
Connected at 16800 bps
40
CONNECT 300 *
Connected at 300 bps
55
CONNECT 21600 *
Connected at 21600 bps
56
CONNECT 24000 *
Connected at 24000 bps
57
CONNECT 26400 *
Connected at 26400 bps
58
CONNECT 28800 *
Connected at 28800 bps
59
CONNECT 31200 *
Connected at 31200 bps
60
CONNECT 33600 *
Connected at 33600 bps
70
CONNECT 32000 *
Connected at 32000 bps, 56K rate
71
CONNECT 34000 *
Connected at 34000 bps, 56K rate
72
CONNECT 36000 *
Connected at 36000 bps, 56K rate
73
CONNECT 38000 *
Connected at 38000 bps, 56K rate
74
CONNECT 40000 *
Connected at 40000 bps, 56K rate
75
CONNECT 42000 *
Connected at 42000 bps, 56K rate
76
CONNECT 44000 *
Connected at 44000 bps, 56K rate
77
CONNECT 46000 *
Connected at 46000 bps, 56K rate
78
CONNECT 48000 *
Connected at 48000 bps, 56K rate
79
CONNECT 50000 *
Connected at 50000 bps, 56K rate
80
CONNECT 52000 *
Connected at 52000 bps, 56K rate
81
CONNECT 54000 *
Connected at 54000 bps, 56K rate
82
CONNECT 56000 *
Connected at 56000 bps, 56K rate
* When the extended result code configuration option is enabled, one of the following codes is append-
ed to the result code, depending on the type of error control connection:
V42bis – V.42 error control (LAP-M) and V.42bis data compression
V42 – V.42 error control (LAP-M) only
MNP5 – MNP 4 error control and MNP 5 data compression
MNP4 – MNP 4 error control only
NoEC – No error control protocol
