140

802.1Q Configuration

1.

Enable GVRP Protocol: check the check box to enable GVRP protocol.

2. Select the port that wants to configure.

3.

Link Type: there are 3 types of link type.

Access Link:

Trunk Link:

Hybrid Link:

4.

Untagged VID: assign the untagged frame VID.

5. Tagged VID: assign the tagged frame VID.

6. Click

Apply

7. You can see each port setting in the below table on the screen.


Group Configuration

Edit the existing VLAN Group.

1. Select the VLAN group in the table list.

2. Click

Apply
