Set-back configuration setup (continued) – MITSUBISHI ELECTRIC LT-4260 User Manual
Page 18
17
Set-Back Configuration Setup (continued)
6. Grasp the HD-6000 from the top and bottom. Slide the HD-6000 into place making sure that all 4
mounting hooks connect to the corresponding pin located on the LCD Display stand.
PIN ON LCD Display
PIN ON LCD Display
PIN ON LCD Display
PIN ON LCD Display
HOOK ON HD6000
HOOK ON HD6000
HOOK ON HD6000
HOOK ON HD6000
