Basic Principles of Operation

5-8

Maxtor D540X-4K 20.4/40.0/60.0/80.0 GB AT

• Flash A/D Converter

• Viterbi Detector

• ENDEC

• Servo Processor

• Clock Synthesizer

• PLL

• Serial Interface

• TA Detection and Correction

2TG %QORGPUCVQT

The pre-compensator introduces pre-compensation to the write data received from
the sequencer module in the DCIIA. The pre-compensated data is then passed to the
R/W Pre-Amplifier and written to the disk. Pre-compensation reduces the write
interference from adjacent write bit.

8CTKCDNG )CKP #ORNKHKGT 8)#

Digital and analog controlled AGC function with input attenuator for extended range.

$WVVGTYQTVJ (KNVGT

Continuous time data filter which can be programmed for each zone rate.

(+4 (KPKVG +ORWNUG 4GURQPUG (KNVGT

Digitally controlled and programmable filter for partial response signal conditioning.

(NCUJ #& %QPXGTVGT

Provides very high speed digitization of the processed read signal.

8KVGTDK &GVGEVQT

Decodes ADC result into binary bit stream.

'0&'%

Provides 16/17 or 24/25 code conversion to NRZ. Includes preamble and sync mark
generation and detection.

5GTXQ 2TQEGUUQT

Servo processor with servo data recovery and burst demodulation.

%NQEM 5[PVJGUK\GT

Provides programmable frequencies for each zone data rate.

2..

Provides digital read clock recovery.
