Table 3-3 logical addressing format, Table 3-3, Logical addressing format -18 – Maxtor D540X-4K User Manual
Page 36: Logical addressing format

Installation
3-18 Maxtor D540X-4K 20.4/40.0/60.0/80.0 GB AT
6CDNG
Logical Addressing Format
Note:
*Capacity may be restricted to 8.4 GB (or less) due to system
BIOS limitations. Check with your system manufacturer to de-
termine if your BIOS supports LBA Mode for hard drives greater
than 8.4 GB. Default logical cylinders is limited to 16,383 by the
ATA standard.
To match the logical specifications of the drive to the drive type of a particular
BIOS, consult the system’s drive-type table. This table specifies the number of
cylinders, heads, and sectors for a particular drive type.
5.
Boot the system using the operating system installation disk—for example,
MS-DOS—then follow the installation instructions in the operating system
manual.
/#:614 &: -
LBA Capacity
20,416 MB
40,037 MB
60,040 MB
80,026 MB
CHS Capacity
8,455 MB*
(Default)
20,416 MB
(Configurable)
8,455 MB*
(Default)
40,037 MB
(Configurable)
8,455 MB*
(Default)
60,040 MB
(Configurable)
8,455 MB*
(Default)
80,026 MB
(Configurable)
Logical Cylinders
16,383*
16,383*
16,383*
16,383*
Logical Heads
16
16
16
16
Logical Sectors/
Track
63
63
63
63
Total Number
Logical Sectors
39,876,480
78,198,750
117,266,688
156,301,488
