8. display board dip switch settings – Miller Electric PipePro Dual User Manual
Page 24
OM-230 009 Page 20
5-8. Display Board DIP Switch Settings
Remove wrapper.
1
DIP Switch S1 And S4
.
DIP switches S1 and S4 should remain in
the factory default settings.
Install wrapper when finished.
804 666-B / 803 063
1
1 2 3 4 5 6 7 8
O
N
Factory Set Default Settings
For DIP Switches S1 And S4
.
In the DIP switch S1and S4 il-
lustration, the elevated slider on
each switch is shown in white. For
example, the switches above are
all in the Off position.
Tools Needed:
1/4 in
