3-2. Symbols And Definitions
.
Some symbols are found only on CE products.
A
Amperes
V
Volts Alternating Current
X
Duty Cycle
IP
Degree Of
Protection
Hz
Hertz Program Wire Feed
Jog Output Trigger Line Connection
Set Up Sequence Trigger Hold On Trigger Hold Off
Purge Press To Set Start Crater
Time Preflow Time Postflow Time Read Instructions
Increase
I
1
Primary Current
I
2
Rated Current
U
2
Load Voltage
U
1
Primary Voltage
A
B
Dual Schedule
SECTION 4 − INTRODUCTION
4-1. Specifications
Type of Input
Power
Welding Power
Source Type
Wire Feed Speed
Range
Wire Diameter
Range
Welding
Circuit
Rating
IP
Rating
Overall
Dimensions
Weight
40 Volts DC
10 Amperes
PipePro 450 RFC with
14-Pin And Contactor
Control
50 To 780 ipm
(1.3 To 19.8 mpm)
.023 To 1/8 in
(0.6 To 3.2 mm)
Max Spool
Weight: 60 lb
(27 kg)
100 Volts,
750
Amperes,
100% Duty
Cycle
IP 21 Length: 35 in
(889 mm)
Width: 12-1/2 in
(318 mm)
Height: 14 in
(356 mm)
87 lb
(39.5 kg)
