11
PC analog RGB input
Use to input video signals (analog RGB) of a personal computer.
(Pin assignment of Mini D-SUB 15P jack)
PIN NO.
1
2
3
4
5
6
7
8
PIN NO.
9
10
11
12
13
14
15
SPEC
-
GROUND
GROUND
-
HD/CS
VD
-
SPEC
R(RED) / Cr
G(GREEN) / Y
B(BLUE) / Cb
GROUND
GROUND
GROUND
GROUND
GROUND
RS-232C input
• Connect here when you control this Projector with a personal computer
using PCGC (personal computer graphic controller) or with a remote
controller using SpacePointer function.
• The Pin assignment is DTE (Data Terminal Equipment) type.
• Please use RS-232C crossover cable provided.
(Pin assignment of D-SUB 9P jack)
ventilation slots
Used to protect the projector from overheating.
See page 47.
ventilation air filter
This prevents dust from entering inside the
projector. See page 47.
foot adjustment
Use to adjust the angle of the projector.
See page 15.
Note: Be sure to retract them when
packing up the projector.
PIN NO.
1
2
3
4
5
6
7
8
9
CODE
CD
RD
SD
ER
SG
DR
RS
CS
CI
NAME
Carrier Detect
Receive Data(RXD)
Send Data(TXD)
Equipment Ready(DTR)
Signal Ground
Data Set Ready(DSR)
Request to Send(RTS)
Clear to Send(CTS)
Ring Indicator
Bottom side
NOTE
not connected
connected to inner circuit
connected to inner circuit
connected to inner circuit
connected to inner circuit
connected to inner circuit
connected to inner circuit
connected to inner circuit
not connected
I/O
INPUT
INPUT
OUTPUT
OUTPUT
OUTPUT
OUTPUT
INPUT
INPUT
1 5
11
6 10
15
1
6 9
5
