1-1
Product Overview
Chapter 1
Product Overview
Thank you for choosing the IM-945GSE Series (MS-
9830 v1.X) Mini ITX mainboards from MSI.
Based on the innovative Intel ® 945GSE & ICH7M con-
trollers for optimal system efficiency, the IM-945GSE
Series accommodate the latest Intel
® Atom TM processor
N270 (1.6GHz single core with HT) and support one
DDR2 533/667/800 SO-DIMM slot to provide the maxi-
mum of 1GB memory capacity.
Three options are available for the IM-945GSE Series:
Option A
ATX Power, High Rear I/O, DVI, VGA,
1 RS-232/422/485 Port, 5 RS-232 Ports
Option B
DC Power, Low Rear I/O, DVI-I,
1 RS-232/422/485 Port, 4 RS-232 Ports
Option C
DC Power, Low Rear I/O, VGA, LVDS,
1 RS-232/422/485 Port, 4 RS-232 Ports
Option D
DC Power, High Rear I/O, DVI, VGA,
1 RS-232/422/485 Port
Option E
DC Power, High Rear I/O, VGA, LVDS,
1 RS-232/422/485 Port, 4 RS-232 Ports
