3
99-8219
KIT ASSEMBLY
Mount the ISO Brackets to the
aftermarket radio using the
screws supplied with the radio.
(Figure B) 2
Slide the radio into the radio
housing until the side clips
engage. Snap the Trim-plate into
the Radio Housing. (Figure C) 3
Slide the housing brackets onto
the side of the radio housing until
the clips engage. Note: Brackets
are marked left and right. (Figure A) 1
ISO RADIO PROVISION WITH POCKET
A
B
C
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
