Metra Electronics 99-8219 - Manual (Page 4)

2
99-8219
KIT ASSEMBLY
Slide the aftermarket radio into the
cage and secure. (Figure C) 3
Slide the housing brackets onto
the side of the radio housing until
the clips engage. Note: Brackets
are marked left and right. (Figure A) 1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs outward.
(Figure B) 2
DIN RADIO PROVISION WITH POCKET
A
B
C
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
