2
Important Safety Instructions and Precautions
WARNING: DO NOT connect directly to the Public Switched Telephone Network
(PSTN). ANY CONNECTION OF THIS SET TO AN OFF PREMISE
APPLICATION, AN OUT OF PLANT APPLICATION, ANY OTHER EXPOSED
PLANT APPLICATION, OR TO ANY EQUIPMENT OTHER THAN THE
INTENDED APPLICATION MAY RESULT IN A SAFETY HAZARD, AND/OR
DEFECTIVE OPERATION, AND/OR EQUIPMENT DAMAGE. “EXPOSED
PLANT” MEANS WHERE ANY PORTION OF THE CIRCUIT IS SUBJECT TO
ACCIDENTAL CONTACT WITH ELECTRIC LIGHTING OR POWER
CONDUCTORS OPERATING AT A VOLTAGE EXCEEDING 300 V BETWEEN
CONDUCTORS OR IS SUBJECT TO LIGHTNING STRIKES.
WARNING: THE SOCKET OUTLET, IF USED, SHALL BE LOCATED NEAR
THE EQUIPMENT AND SHALL BE EASILY ACCESSIBLE BY THE USER.
WARNING: ONLY MITEL NETWORKS APPROVED AC POWER ADAPTERS
SHALL BE USED.
NOTE: SOME IP PHONES DO NOT REQUIRE A DC POWER ADAPTER IF POWER
OVER THE LAN COMPLIANT WITH IEEE 802.3af IS AVAILABLE.
WARNING: The connector marked
is ONLY for the PDA device charger
power supply that came with your PDA device. Using any other power supply may
result in fire or explosion.
CAUTION: THE HANDSET SUPPLIED WITH THE IP PHONE IS NOT
CERTIFIED FOR USE WITH ANY OTHER PHONE. USE OF THE
HANDSET WITH ANY OTHER PHONE MAY HAVE THE POTENTIAL TO
CAUSE HEARING LOSS IN THE EVENT OF A LIGHTNING STRIKE ON
THE OUTSIDE PLANT WIRING.
When using your telephone equipment, basic safety precautions should always
be followed to reduce the risk of fire, electric shock and injury to persons,
including the following:
• Do not use this product near water, for example, near a bath tub, wash bowl,
kitchen sink or laundry tub, in a wet basement or near a swimming pool.
• Avoid using a telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
• Do not use the telephone to report a gas leak in the vicinity of a leak.
Maintenance and Repair
The 5230 IP Appliance is a field replaceable unit. There are no user serviceable
parts inside the set. For repairs, return the set to an authorized Mitel Networks
dealer.
These notices may appear on the product or in the technical documentation.
This symbol may appear on the product.
Disclaimer
The information contained in this document is believed to be accurate in all
respects but is not warranted by Mitel Networks™ Corporation. The information
is subject to change without notice and should not be construed in any way as
a commitment by Mitel Networks or any of its affiliates or subsidiaries. Mitel
Networks and its affiliates and subsidiaries assume no responsibility for any
errors or omissions in this document. Revisions of this document or new
editions of it may be issued to incorporate such changes. Nothing in this
document may be reproduced in any manner, wether wholly or in part for any
use whatsoever, without written permission from Mitel Networks Corporation.
Mitel and Mitel Networks are trademarks of Mitel Networks Corporation.
IMPORTANT! This telephone is NOT suitable for direct connection to the
public-switched telephone network. Connect this telephone to a Mitel Networks
system only.
Introduction
The 5230 IP Appliance uses your Personal Digital Assistant (PDA) as an
intuitive interface to your telephone system. With the 5230 IP Appliance PDA
Applications installed on your PDA, you can, for example, make calls from your
Contact list, synchronize your data and files, view a list of your voice mails, or
share files with other 5230 IP appliance users.
Contents
To install the PDA Personality Module
1. Select viewing angle (— or - -) (see Figure ).
2. Insert pivots first ( n ), then latches( o ). Press latches outward to lock in
place.
3. Squeese the tab of the cover and lift the cover up to remove it
(see Figure ).
4. Insert the Personality Module (see Figure ). Make sure that the
Personality Module is compatible with your PDA (the number on the
Personality Module sticker should match the model number of your PDA).
5. Connect to LAN, to computer, to handset, to headset,
and to the charger that came with your PDA (see Figure ).
The USB connector ( ) is for future use.
Installing the 5230 Applications
1. If it’s not already done, follow the instructions in your PDA documentation
to set up your PDA and synchronize it with your computer.
2. Insert your PDA in its synchronization cradle (NOT in the 5230 IP
Appliance), then insert the 5230 IP Appliance PDA Applications CD-ROM
in your computer.
3. The installation program starts automatically. Follow the prompts to install
the applications on your PDA. The selected applications are installed on
your computer and your PDA. For more details on the installation procedure,
refer to the 5230 IP Appliance User Guide (see box).
4. When the setup program is finished, click Finish.
5. Remove the PDA from its cradle, and insert it in the 5230 Personality
Module.
Note: Keep your PDA synchronization cradle. You will need it to upgrade
your 5230 Applications software.
6. On your PDA, select the PDA Startup application in the Start menu. You
are now ready to use your 5230 IP Appliance.
Using a Local Power Supply
You must use a local power supply if your LAN cannot provide the power for
your 5230 IP Appliance.
1. Connect the LAN cable to the LAN connector of the local power supply.
2. Connect an Ethernet cable from the Phone connector on the local power
DANGER
Danger indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
Warning indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Caution indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury and/or damage to the equipment
or property.
The exclamation point within an equilateral triangle indicates that
important operating and maintenance (servicing) instructions are included
in the literature accompanying the product.
!
5230 IP Appliance box:
• 5230 IP Appliance set
• handset with cord
• RJ-45 (Ethernet) cable
• Installation Guide (this
document)
5230 Personality Module box:
• Personality Module
• 5230 IP Appliance PDA Applications
CD-ROM
• Power supply (if ordered)
• local power supply
User Documentation
To download the 5230 IP Appliance User Guide and Quick Reference
Guide:
(1) go to www.mitel.com; (2) bring your cursor over the word Support, and
select Documentation Library; (3) in the list, select User Guides.
A
B
C
D
