XTA Electronics Ltd DP448 Library File LCDLCWLX02_448v4.xbl 10:25 11.Oct.2007
W8LCD+14W8LC Lo Crv HFB+WLX Amps 32dB
Format: Free Assignment Name: LCD14LC LCHFB LX
Output [1] LF W8LCD (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
60.1Hz 24dB Link/Riley 270Hz 24dB Link/Riley
+4.0dB 0.0000 mS [Linked to Output 4]
Attack: 16mS Release: x16 at +5dB Fast at 12dB above Limiter
54.6Hz
3.0
+5.0dB
PEQ
154Hz
4.0
-6.0dB
PEQ
223Hz
2.0
+2.0dB
PEQ
105Hz
2.0
-1.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [2] MF W8LCD (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
327Hz 24dB Link/Riley 3k00Hz 24dB Link/Riley
+0.0dB 2.0260 mS [Linked to Output 4]
Attack: 2.0mS Release: x16 at +2dB Fast at 12dB above Limiter
618Hz
3.0
-3.0dB
PEQ
1k10Hz
4.0
+4.0dB
PEQ
2k77Hz
4.0
+5.0dB
PEQ
1k00Hz
0.71
+5.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [3] HF W8LCD (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
3k00Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
+0.0dB 2.0391 mS [Linked to Output 4]
Attack: 0.7mS Release: x16 at +1dB Fast at 12dB above Limiter
5k04Hz
2.0
-3.0dB
PEQ
14k0Hz
3.0
+6.0dB
PEQ
5k04Hz
0.71
+4.0dB
High Shelf
1k00Hz
0.71
+4.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [4] LF W8LC (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
60.1Hz 24dB Link/Riley 270Hz 24dB Link/Riley
+4.0dB 0.7500 mS
Attack: 16mS Release: x16 at +5dB Fast at 12dB above Limiter
54.6Hz
3.0
+5.0dB
PEQ
154Hz
4.0
-6.0dB
PEQ
223Hz
2.0
+2.0dB
PEQ
105Hz
2.0
-1.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [5] MF W8LC (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
334Hz 24dB Link/Riley 3k00Hz 24dB Link/Riley
+0.0dB 2.1009 mS [Linked to Output 4]
Attack: 2.0mS Release: x16 at +2dB Fast at 12dB above Limiter
2k94Hz
4.0
+3.0dB
PEQ
1k00Hz
0.71
+5.0dB
High Shelf
891Hz
1.5
-3.0dB
PEQ
500Hz
1.00
-3.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [6] HF1 W8LC (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k67Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
-2.0dB 2.0618 mS [Linked to Output 4]
Attack: 0.7mS Release: x16 at +1dB Fast at 12dB above Limiter
4k40Hz
1.5
-2.0dB
PEQ
5k04Hz
0.71
+4.0dB
High Shelf
10k1Hz
2.5
+4.0dB
PEQ
1k00Hz
0.71
+4.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [7] HF2 W8LC (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k67Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
-2.0dB 2.0618 mS [Linked to Output 4]
Attack: 0.7mS Release: x16 at +1dB Fast at 12dB above Limiter
4k40Hz
1.5
-2.0dB
PEQ
5k04Hz
0.71
+4.0dB
High Shelf
8k00Hz
2.5
+7.0dB
PEQ
1k00Hz
0.71
+5.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [8] WLX (Source = Input B)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
20.1Hz 24dB Link/Riley 80.3Hz 24dB Link/Riley
+5.0dB 0.0000 mS
Attack: 45mS Release: x16 at +7dB Fast at 12dB above Limiter
40.1Hz
1.7
+5.0dB
PEQ
70.2Hz
5.0
+2.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Fly upper W8LCD from W8LC 6deg hole. Fly lower W8LCD from upper W8LCD using hole provided. 1
W8LCD is usually optimum.
Design arrays using DISPLAY(tm) predictions. Refer to relevant User Guides CD Rigging Manuals for
safety information.
