XTA Electronics Ltd DP448 Library File LM_WMX03_448v4.xbl 17:21 11.Oct.2007
6W8LM + WMX High Curve Stereo
Format: 2 x 3 Way + Aux Crossover Name: 6LM+WMX HCrvST
Output [1+4] LM L LF (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
70.2Hz 24dB Link/Riley 2k12Hz 24dB Link/Riley
+0.0dB 0.1019 mS [Linked to Output 3]
Attack: 16mS Release: x16 at +4dB Fast at 12dB above Limiter
90.1Hz
1.19
+6.0dB
PEQ
583Hz
1.3
-6.0dB
PEQ
891Hz
6.0
-1.5dB
PEQ
1k33Hz
5.0
+3.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [2+5] LM L HFa (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k00Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
+0.0dB 0.0000 mS [Linked to Output 3]
Attack: 0.7mS Release: x16 at -1dB Fast at 12dB above Limiter
4k00Hz
2.0
-4.0dB
PEQ
1k00Hz
0.71
+1.5dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [3+6] LM L HFb (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k00Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
+0.0dB 3.8311 mS
Attack: 0.7mS Release: x16 at -1dB Fast at 12dB above Limiter
4k00Hz
2.0
-4.0dB
PEQ
2k52Hz
0.71
+1.5dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [7+8] WMX L (Source = Input C)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
20.1Hz 24dB Link/Riley 80.3Hz 24dB Link/Riley
+0.0dB 0.4300 mS
Attack: 45mS Release: x16 at +7dB Fast at 12dB above Limiter
40.1Hz
1.7
+5.0dB
PEQ
70.2Hz
5.0
+2.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
