Martin Audio DX2 - Manual (Page 105)

XTA Electronics Ltd DP448 Library File LDLBLS02_448v4.xbl 10:50 11.Oct.2007
W8LD+6LongBow HF Norm+W8LS Amps32dB
Format: Free Assignment Name: LD+6LngB HFN+LS
Output [1] LF W8LD (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
60.1Hz 24dB Link/Riley 231Hz 24dB Link/Riley
+0.0dB 0.1872 mS [Linked to Output 4]
Attack: 16mS Release: x16 at +7dB Fast at 12dB above Limiter
54.6Hz
3.0
+6.0dB
PEQ
75.8Hz
5.0
+3.0dB
PEQ
111Hz
2.0
-1.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [2] MF W8LD (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
202Hz 24dB Link/Riley 2k83Hz 24dB Link/Riley
-3.0dB 3.1872 mS [Linked to Output 4]
Attack: 4.0mS Release: x16 at +2dB Fast at 12dB above Limiter
655Hz
5.0
-3.0dB
PEQ
1k10Hz
4.0
+4.0dB
PEQ
2k24Hz
0.71
+3.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [3] HF W8LD (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k67Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
-3.0dB 2.7201 mS [Linked to Output 4]
Attack: 1.0mS Release: x16 at +1dB Fast at 12dB above Limiter
4k16Hz
5.0
-7.0dB
PEQ
14k0Hz
1.00
+6.0dB
PEQ
2k24Hz
0.71
+3.0dB
High Shelf
6k99Hz
0.71
+2.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [4] LF LngBw (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
60.1Hz 24dB Link/Riley 231Hz 24dB Link/Riley
+0.0dB 0.0000 mS
Attack: 16mS Release: x16 at +7dB Fast at 12dB above Limiter
54.6Hz
1.4
+4.0dB
PEQ
70.2Hz
5.0
+3.0dB
PEQ
111Hz
2.0
-1.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [5] MF LngBw (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
202Hz 24dB Link/Riley 2k83Hz 24dB Link/Riley
-6.0dB 2.9502 mS [Linked to Output 4]
Attack: 4.0mS Release: x16 at +4dB Fast at 12dB above Limiter
2k12Hz
3.0
+3.0dB
PEQ
2k52Hz
3.0
+2.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
463Hz
2.2
-4.5dB
PEQ
2k24Hz
0.71
+3.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [6] HF1 LngB (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k67Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
-12.0dB 3.1292 mS [Linked to Output 4]
Attack: 1.0mS Release: x16 at +4dB Fast at 12dB above Limiter
4k32Hz
2.0
-4.0dB
PEQ
6k99Hz
0.71
+2.0dB
High Shelf
12k0Hz
1.5
+3.0dB
PEQ
2k24Hz
0.71
+3.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [7] HF2 LngB (Source = Input A)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
2k67Hz 24dB Link/Riley >32k0Hz 24dB Link/Riley
-12.0dB 3.1292 mS [Linked to Output 4]
Attack: 1.0mS Release: x16 at +4dB Fast at 12dB above Limiter
4k32Hz
2.0
-4.0dB
PEQ
6k99Hz
0.71
+2.0dB
High Shelf
12k0Hz
1.5
+3.0dB
PEQ
2k24Hz
0.71
+3.0dB
High Shelf
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Output [8] W8LS (Source = Input B)
Freq.
Q
Gain
Type
Highpass:
Gain:
Limiter:
Lowpass:
Delay:
Clip Limiter:
PEQ 1 PEQ 2 PEQ 3 PEQ 4 PEQ 5 PEQ 6 PEQ 7 PEQ 8 PEQ 9
20.1Hz 24dB Link/Riley 80.3Hz 24dB Link/Riley
+0.0dB 5.5000 mS
Attack: 45mS Release: x16 at +7dB Fast at 12dB above Limiter
35.1Hz
1.4
+6.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
1k00Hz
3.0
+0.0dB
PEQ
Fly upper W8LD from Longbow 6deg hole. Fly lower W8LD from upper W8LD with 20deg splay hole. 1
W8LD is usually optimum.
Design arrays using DISPLAY(tm) predictions. Refer to relevant User Guides CD Rigging Manuals for
safety information.
