EDS-508 Series User’s Manual Featured Functions
3-45
Configuring Rate Limiting
Ingress Policy
Setting Description Factory Default
Limit All
Selecting this option prohibits all traffic of
broadcast, multicast, unicast packets that exceed the
rate set in the following “Rate” field.
Limit Broadcast
Selecting this option prohibits all traffic of
broadcast packets that exceed the rate set in the
following “Rate” field.
Limit Broadcast
and Multicast
Selecting this option prohibits all traffic of
broadcast and multicast packets that exceed the rate
set in the following “Rate” field.
Limit Broadcast,
Multicast, and
flooded unicast
Selecting this option prohibits all traffic of
broadcast, multicast, and flooded unicast (the new
unicast address never learned by the EDS) packets
that exceed the rate set in the following “Rate”
field.
Limit Broadcast
Rate of Low Priority Queue
Setting Description Factory Default
128K/256K/512K
/1M/2M/4M/8M Set the threshold of traffic of limited packets in
EDS’s low priority queue.
8M
Rate of Normal Priority Queue
Setting Description Factory Default
The same or
double rate of
low priority
queue
Set the threshold of traffic of limited packets in
EDS’s Normal priority queue.
8M
