EDS-508 Series User’s Manual Featured Functions
3-39
Port Type
Setting Description Factory Default
Access
This port type is used to connect single devices
without tag.
Trunk
Select ”Trunk” port type to connect another 802.1Q
VLAN aware switch or another LAN that combines
tagged and/or untagged devices and/or other
switches/hubs.
Access
For communication redundancy in the VLAN environment, set “Redundant Port,” “Coupling
Port,” and “Coupling Control Port” as “Trunk Port,” since these ports act as the “backbone” to
transmit all packets of different VLANs to different EDSs.
Management VLAN Setting
Setting Description Factory Default
VID range
from 1 to 4094
Set the management VLAN of this EDS-508. 1
Port PVID
Setting Description Factory Default
VID range
from 1 to 4094 Set the port default VLAN ID for untagged devices
that connect to the port.
1
Port Fixed VLAN List (Tagged)
Setting Description Factory Default
VID range
from 1 to 4094
This field will be active only when selecting the
“Trunk” port type. Set the other VLAN ID for tagged
devices that connect to the “Trunk” port. Use commas
to separate different VIDs.
None
Port Forbidden VLAN List
Setting Description Factory Default
VID range
from 1 to 4094
This field will be active only when selecting the
“Trunk” port type. Set the VLAN IDs that will not be
supported by this trunk port. Use commas to separate
different VIDs.
None
