Elite Admin Configuration 5-11
Note: If the log file is not backed up once the designated file size limit is
reached, data thereafter will be lost. Also note that a separator
line is added to the log file after each Dispatch session. This
happens when Dispatch is started up or the dispatch user changes
to another configuration file then back to the current configuration
file.
In Audible Indication, the ability is enabled to hear a tone in Dispatch
when an event is received.
Note: if this is selected make sure to “turn off” Enable Tones on
Status/Message on the Edit/Current Configuration screen.
In Customize Inbound Event Display, Total Rows to be shown in the
display window can be specified by entering the number of rows desired.
Selected Content refers to the title that appears at column headings of the
display. The up and down arrows are used to position a column on the
IED window from left to right: closer a selection is located to the top of
the list, closer the column appears toward the left of the display. The
following table provides a description for each item on the Selected
Content listing.
Note: If Event State is checked it must be the top entry in the list.
Note: The Primary Resource and Event State columns do not have
heading titles displayed at the top of their respective columns.
Item Description
Event State
UnAcknowledged, Acknowledged, Held
Resource The resource name
Unit Alias The alias for the unit
Alias The alias for the Status Code/Message Code
Time The time stamp of the event
Primary
Resource A Primary Resource indicator ( * - an asterisk). No
indicator will mean the resource is not primary.
Unit ID The Unit ID
Event A text wording of the message code
Code The Message code of the event
Secure Key A resource’s encryption key number.
