Metra Electronics 99-7875T - Manual (Page 7)

99-7875/7875T KIT ASSEMBLY
5
A
B
C
ISO MOUNT RADIO PROVISION WITH POCKET
Mount the ISO Brackets to the radio
using the screws supplied with the
radio. (Figure A) 1
Slide the radio into the Radio Housing
until it snaps into place. (Figure B) 2
Snap the Trim Plate onto the front of
the Radio Housing. (Figure C) 3
Snap the Pocket into the Radio
Housing. (Figure C) 4
Continue to final assembly.
* Note: Refer also to the instructions included with the aftermarket radio.
