99-7875/99-7875T DASH DISASSEMBLY
2
Remove (2) Phillips screws facing up
on the bottom of the factory radio.
(Figure H) 9
Unclip and remove the hazard
switch/passenger air bag light
assembly. (Retain the hazard
switch/passenger air bag light
assembly for re-use during kit prepa-
ration.) 13
Remove (4) Phillips screws securing
trim panel at the bottom edge of the
factory radio assembly and remove
the trim panel. (Retain the screws
and trim panel for re-use during kit
preparation.) 14
Remove (9) clips from the back of the
factory radio assembly. (Retain the
clips for re-use during kit prepara-
tion.) 15
Remove (6) Phillips screws securing
the climate controls to the factory
radio assembly and remove the con-
trols from the assembly. (Retain the
screws and climate controls for re-
use during kit preparation.) 11
Remove (4) Phillips screws securing
the a/c vents to the factory radio
assembly and remove the a/c vent
from the assembly. (Retain the
screws and a/c vents for re-use dur-
ing kit preparation.) 12
Unclip the factory radio assembly.
Unplug and remove the radio assem-
bly. (Figure I) 10
Continue to kit preparation.
I
G
H
F
HONDA ACCORD 2008-10 / CROSSTOUR 2010
