Parts Lists and Locations
The following parts lists and parts location drawings reflect the latest issue of
hardware at the time of printing.
Parts locations are illustrated as follows:
Model Parts List Parts Location Drawing
MVME712x
MVME712-12 Primary side - Figure 3-1
MVME712-13 Primary side - Figure 3-2
MVME712A Primary side - Figure 3-3
MVME712AM Primary side - Figure 3-4
MVME712x Table 3-15 Secondary side - Figure 3-5
MVME712B Table 3-16 Figure 3-6
LCP2 adapter Table 3-17 Figure 3-7
Table 3-15. MVME712 x Module Parts List
Reference
Designation
Motorola
Part Number
Description
84-W8832B01A Printed wiring board
(MVME712-12, MVME712-13)
84-W8838B01B Printed wiring board
(MVME712A, MVME712AM)
CR1,CR2 48NW9607A20 RectiÞer, Schottky
CR3-CR29 48NW9644A01 Diodes, zener, 2V and 15V
C1,C2 21NW9604A81 Capacitor, Þxed, ceramic, 330 pF @ 1K Vdc
C3 23NW9618A33 Capacitor, electrolytic, 22
µ
F @ 25 Vdc
C4-C7 21NW9711A14 Capacitor, SMD, ceramic, 330 pF @ 50 Vdc
C8-C10 21NW9711A02 Capacitor, SMD, ceramic, 0.1
µ
F @ 50 Vdc
J1,J3-J5 29NW9802H73 Connector, subminiature, 9-pin plug
J2 28NW9802J57 Connector, 6-pin
J6 28NW9802H56 Connector, double row, 2-pin socket
J7 28NW9802H49 Connector, double row, 20-pin socket
J8,J9,J13,J14
J16,J17 29NW9805C07 Pin, autoinsert (32 required)
