20
English
B
A
TTERIES AND C
HARGERS
Charging a Stand-Alone Battery
To charge a battery whilst not attached to the
radio - at step 4 above, insert the battery into
the tray, with the inside surface of the battery
facing the front of the charger, as shown.
Ensure the slots in the battery correctly engage
in the charger.
Important: Ensure that the bracket in the charger is
adjusted to the correct position for
either Standard or High-capacity
battery. See "Charging a Standard
Battery" on page 20.
Charging a Standard Battery
The drop-in tray charger has a removable
bracket that is adjustable depending on the
type of battery that needs to be charged. It is
designed to charge either the battery (with the
radio) or a standalone battery. The drop-in tray
charger comes by default set up to charge a
standard battery. The following image on page
page 21 shows the orientation for each battery:
