9820/9830/9835ervice Manual Connectors and Cables
TC9830SM Rev. B 7/98 Confidential July 1998 52
1 + 25 VDC
2 SM PH A
3 SM PH A bar
4 + 25 VDC
5 SM PH B
6 SM PH B bar
Figure B- 3. CN 3 Platen Stepper Motor
1 LED 1 1 2 + 5 VDC
3 CHASSIS GROUND 4 DISPLAY CLK
5 CHASSIS GROUND 6 DISPLAY LATCH
7 CHASSIS GROUND 8 DISPLAY DATA
9 KEY 1 A 10 CHASSIS GROUND
11 KEY 2 A 12 CHASSIS GROUND
13 KEY 3 A 14 CHASSIS GROUND
15 LED 2 16 LED 3
Figure B- 4. CN 4 Control Panel
1 F PP STROBE bar 1 2 CHASSIS GROUND
3 LC PD00 4 CHASSIS GROUND
5 LC PD01 6 CHASSIS GROUND
7 LC PD02 8 CHASSIS GROUND
9 LC PD03 10 CHASSIS GROUND
11 LC PD04 12 CHASSIS GROUND
13 LC PD05 14 CHASSIS GROUND
15 LC PD06 16 CHASSIS GROUND
17 LC PD07 18 CHASSIS GROUND
19 N/C 20 CHASSIS GROUND
21 F MC BUSY 22 CHASSIS GROUND
23 F MC PERROR 24 CHASSIS GROUND
25 F MC SELECT 26 F MC INIT bar
27 N/C 28 N/C
29 N/C 30 N/C
31 N/C 32 N/C
33 N/C 34 N/C
35 + 5 VDC 36 CHASSIS GROUND
37 N/C 38 N/C
39 N/C 39 40 N/C
Figure B- 5. CN 5 Coax/Twinax Interface
