CHAPTER 2 FUNCTIONAL DESCRIPTION
OVERVIEW OF MODULES
•
Power Transformer Assembly (Power Supply and Distribution)
•
Control Board Assy. (Data Handling and Control)
•
Peel Module (Supply/Backing Separation)
•
Print Assembly (Thermal Control and Motion Synchronization)
•
Feed Assembly (Supply Alignment/Tension)
•
Supply Holder Assembly (Supply Guide)
•
Control Panel Assembly (Operator Interface)
Control Board
Assy.
AC Inlet
Module
Power
Transformer
Assy.
Rectifier
Control Panel Assembly (Mounted
to printer housing- not shown)
Peel Module
(inside door of 9830)
Supply Holder Assy.
Print Assembly
