APPENDIX B CONNECTORS AND CABLES
This appendix contains charts of the pinouts for the Control Board Assembly connectors
1 F PP STROBE bar 1 2 LC PD00
3 LC PD01 4 LC PD02
5 LC PD03 6 LC PD04
7 LC PD05 8 LC PD06
9 LC PD07 10 F MC ACK bar
11 F MC BUSY 12 F MC PERROR
13 F MC SELECT 14 F MC AUTOFD bar
15 N/C 16 CHASSIS GROUND
17 EMI GROUND 18 N/C
19 CHASSIS GROUND 20 CHASSIS GROUND
21 CHASSIS GROUND 22 CHASSIS GROUND
23 CHASSIS GROUND 24 CHASSIS GROUND
25 CHASSIS GROUND 26 CHASSIS GROUND
27 CHASSIS GROUND 28 CHASSIS GROUND
29 CHASSIS GROUND 30 CHASSIS GROUND
31 F MC INIT bar 32 F MC FAULT bar
33 N/C 34 N/C
35 N/C 35 36 F MC SELIN bar
Figure B- 1. CN 1 IEEE 1284 Parallel Port
1 CHASSIS GROUND 1 2 VTPH
3 CHASSIS GROUND 4 VTPH
5 CHASSIS GROUND 6 VTPH
7 CHASSIS GROUND 8 VTPH
9 CHASSIS GROUND 10 VTPH
11 BANK ENABLE OUTPUT 12 CHASSIS GROUND
13 VDAT bar 14 CHASSIS GROUND
15 LATCH bar 16 CHASSIS GROUND
17 TPHCLK 18 CHASSIS GROUND
19 TPH STB B bar 20 TPH STB A bar
21 TPH STB B bar 22 TPH STB A bar
23 TPH STB B bar 24 TPH STB A bar
25 TPH STB A bar 26 N/C
27 V TM 28 VREF
29 + 5 VDC 29 30 + 5 VDC
Figure B- 2. CN 2 Printhead Assembly
