6 right side view, 7 car holder, Right side view car holder – Magellan 800 User Manual
Page 17: Chapter 2: magellan roadmate, 6 right side view 2.7 car holder

Chapter 2: Magellan RoadMate
8
2.6 Right Side View
2.7 Car Holder
1
Battery Compartment Cover
Rechargeable battery.
1
Wire Catcher
Used to secure the power cable.
2
Windshield Mount connection
Insert the notches of the windshield mount here.
3
car holder Release
Press to release Magellan RoadMate from car holder.
4
Mount Screw Holes
Attach another mounting device that requires an adapter plate.
