51
Statistics
When you click
Statistics
in the left hand column of links, the links bar expands to display six statisti-
cal sub-headings:
These screens will var y depending on your Gateway’s model and traffic activity.
☛
Note:
Available Statistics links var y by platform.
DSL
When you click
DSL
, the DSL Statistics page appears.
The DSL Statistics page displays information about the Gateway's WAN connection to the Internet.
◆
Line State: May be Up (connected) or Down (disconnected).
◆
Modulation: Method of regulating the DSL signal. DMT (Discrete MultiTone) allows connections to
work better when cer tain radio transmitters are present.
◆
Data Path: Type of path used by the device's processor.
Downstream and Upstream statistics
◆
Max Allowed Speed (kbps): Your maximum speeds for downloading (receiving) and uploading
(sending) data on the DSL line, in kilobits per second.
◆
SN Margin (db): Signal to noise margin, in decibels. Reflects the amount of unwanted “noise” on
the DSL line.
◆
Line Attenuation: Amount of reduction in signal strength on the DSL line, in decibels.
◆
CRC Errors: Number of times data packets have had to be resent due to errors in transmission or
reception.
