Motion MMI-8S User Manual
Page 48
SPECIFICATIONS - MMI
PARAMETER
MIN MAX UNIT
Power
Motor supply voltage
12
40
VDC
Current (no motor)
150
160
ma
PWM frequency
MD10A
18
24
Khz
Motor current
MS2.0
0.05
2.0
Amp
Step pulse input
Voltage
0
+5.0
VDC
Sink surrent
12
20
ma
Pulse high
1
uSec
Pulse low
1
uSec
Rise time
0.5
uSec
Fall time
0.5
uSec
Frequency
500
KHz
Logic ' 1' volts
+1.8
+2.0
VDC
Direction input
Voltage
0
+5.0
VDC
Sink current
12
20
ma
Logic ' 1' volts
+1.8
+2.0
VDC
Note: The step pulse input must be a logic 1 (high) during direction input change.
Environmental
Operating temperature
-20
+50
C
Humidity (non-condensing)
0
95
%
Shock
100
G
Altitude
30.000
FT
Mechanical
Weight
3
lb
Dimensions
2" x 3.5" x 11.0"
Mounting hole centers
2.625" x 8.250"
Mounting screw size
#6-32 x 1/2" max
